Automatic Cooking Oil / Energy Oil / Dish Soap / Laundry Detergent Line (Piston Filling)
Servo piston filling line for oils and detergents, with caps feeding & capping, caps pressing and aluminum-foil sealing. Filling 50-5000 ml, +/-1% accuracy, liquid-shortage alarm protection.
Servo piston filling, +/-1% accuracy
Caps feeding + capping + pressing + aluminum foil sealing
Liquid-shortage shutdown alarm
Wide volume range 50-5000 ml
| Power | 2.0 KW / 380V, 3-phase 5-wire |
| Protection | Liquid-shortage shutdown alarm |
| Air pressure | 0.6-0.8 MPa (air compressor required) |
| Filling form | Servo piston / 伺服活塞式 |
| applications | Edible oil, Energy/fuel oil, Dish soap, Laundry detergent |
| Capping speed | 20 bottles/min, 500W, 220V single phase |
| Filling heads | 1-12 heads |
| Filling speed | 600-5000 bottles/h |
| Tank capacity | 50 L |
| Conveyor motor | 370W variable-frequency |
| Filling accuracy | +/-1% |
| Filling capacity | 50-500 / 100-1000 / 500-5000 ml |
